Specification

Input voltage : 100-240V AC @ 50/60Hz
Output voltage : 12-14V DC ADJ

Output current : 3A

Charge current : 0.8A Max.

Recommended battery : 12V7Ah

Ripple&Efficiency : 100mV / 82%

Certificates : CE, CB, RoHS

Weight : 0.58kg

LED description

4 LED indicators on the front panel

LED1(Red) : Low Battery

LED2(Amber) : Battery charge indicator

LED3(Green) : DC output indicator

LED4(Red) : AC input indicator
