Model Name

    MH-DVJ30-70

Image Device

1/3" Exview HAD CCD II (ICX673AKA)

DSP Device

Effio-E (CXD4127GG,CXD4816GG)

Resolution

Color Mode: 650TVL; B/W Mode:700TVL

Picture Elements

PAL:976(H)×582(V)    NTSC:976(H)×494(V)

IR Led & IR Range

36pcs ￠5 IR Led; 30M IR Distance

Min. Illumination

0.001 Lux (F2.0)/ 0 Lux IR On

Lens Furnished

Built-in Manual Zoom Lens  2.8--12mm

TV System

PAL/NTSC

Electronic Shutter

NTSC:1/60~1/100,000, PAL:1/50~1/110,000

S/N Ratio

More than 52dB

Gamma

0.45

Exposure

Auto

Shuter/ AGC

Auto/Manual

White Balance

ATW / User1/User2

Backlight

OFF/ON/BLC/ HLC

Pict Adjust

Mirror/Brightness/Contrast/Sharpness/Hue/Gain

ATR

ON/OFF

Motion Det

OFF/ON(Detect sense/ Area Sel)

Peivacy Masking

OFF/ON (4 Zone)

Day/Nigh

True Day and Night (Auto/ Day / Night / Ext. D&N)

2D-NR

OFF/ON (Y/C level)

Camera ID

OFF/ON

Sync. System

Internal

Video Output

1 Vp-p / 75 Ohms

Power Supply

DC12V±10%

Operation Temperature

-10℃ ~ +50℃ RH95% Max

Dimension

¢135 x 86 mm

Weight

1000g
