Specification

      • Listed to UL Standard 864, 9th edition.
      • Built-in DACT (Digital Alarm Communicator/Transmitter)
      • Style B (Class B) IDC (Initiating Device Circuit)
      – SFP-5UD - five IDCs.
      – SFP-10UD - ten IDCs.
      • Style Y (Class B) NAC (Notification Appliance Circuit) - special
      application power
      – SFP-5UD - four NACs.
       – SFP-10UD - four NACs.
      • Notification Appliances may be programmed as
       – Silence Inhibit.
      – Auto-Silence.
       – Strobe Synchronization for System Sensor, Wheelock,
      Gentex, Faraday, or Amseco devices.
      – Selective Silence (horn-strobe mute).
       – Temporal or Steady Signal.
      – Silenceable or Nonsilenceable.

      • Optional N-CAC-5X Style Z (Class A) Converter Module for
         NACs and IDCs (2 required for SFP-10UD).
      • Form-C Relays for Alarm, Trouble and Supervisory - Contact
         Ratings 2.0 A@ 30 VDC or 30 VAC (resistive).
      • 3.0 A total system current for SFP-5UD.
      • 7.0 A total system current for SFP-10UD.
      • Optional Trim Ring TR-CE/-B for semi-flush mounting.
      • 24 volt operation.
      • Low AC voltage sense.
      • Alarm Verification.
      • PAS (Positive Alarm Sequence).
      • Automatic battery trickle charger.
      • Optional Remote Annunciator N-ANN-80.
      • Optional Remote Printer Gateway N-ANN-S/PG.
      • Optional LED Annunciator Driver N-ANN-I/O.
      • Optional 4XTM module (conventional reverse polarity/city
    box transmitter).

USER INTERFACE:


      • Built-in DACT (Digital Alarm Communicator/Transmitter).
      • Integral 80-character LCD display with backlighting and
      keypad.
      • Real-time clock/calendar with automatic daylight savings
      adjustments.
      • ANN-Bus for connection to remote annunciators.
      • Audible or silent walk test capabilities.
      • Piezo sounder for alarm, trouble, and supervisory


Dimensions:

– 20.00" (50.80 cm.) high
– 22.5" (57.15 cm.) wide
– 8.5" (21.59 cm.) deep.
