Input Voltage : |
AC 100 OR 240V |
|
Input Voltage Frequency |
50/60Hz |
|
Output Voltage : |
AC 24V +/-5% |
|
Total Output Current : |
4A |
|
Total Outputs : |
4CH |
|
Fuse Type : |
PTC ( Resettable ) Never need to replace. |
|
Fuse Rating : |
1A |
|
Features : |
|
|
Thermal Cutoffs
Protection (TCO): each output has independent PTC fuse and LED indicator,
when problem occurs, only affect the independent output, other outputs still
working. |
|
|
Short circuit protection:
when short condition occurs, independent PTC fuse will open the circuit, when
condition removed, PTC fuse will automatically back to close. |
|
|
High voltage
protection: when high voltage occurs, the surge protection will be hit
through to protect the connected device. |
|
|
Over Current
protection: when over current occurs, the power supply will automatically
switch to self-protection status, when condition removed, then switch back to
normal. |
|
|
Application : |
CCTV Camera, IP Camera,
PTZ, IR Illuminator, DVR, Access Control , etc. |
|
Packing Dimension : |
256 x 210 x 95 ( mm ) |
|
Net Weight : |
3 KG |
|
Carton Dimension: |
1020*230*295 ( mm )5PCS /Carton |
|
Certification: |
CE/ROHS/UL |
